n: see drift angle.

n: The angle between the tangent of borehole axis and vertical line, measured by inclinometer.

n: see drift angle.

n: See angle of deviation.

n: The rate at which drift angle is increasing as the wellbore is being deviated from vertical. Usually measured in degrees per 100 ft drilled.

n: That part of the wellbores trajectory where the drift angle is increasing.

n: A BHA specially designed to increase drift angle.

n: departure of the wellbore from the vertical, measured by the horizontal distance from the rotary table to the target. The amount of deviation is a function of the drift angle and hole depth. The term is sometimes used to indicate the angle from which a bit has deviated from the vertical during drilling. See drift angle.

n: The angle at which a wellbore diverges from vertical. Wells can deviate from vertical because of the dips in the beds being drilled through. Wells can also be deliberately deviated by the use of a whipstock or other steering mechanism. Wells are often dev

n: an operation made to determine the angle from which a bit has deviated from the vertical during drilling. There are two basic deviation-survey, or driftsurvey, instruments: one reveals the drift angle;the other indicates both the angle and the direction of deviation.

n: See bore-hole surveying.

a record of the deviation angle and the departure usually on a depth unit basis.

n: a logging method that records drift angle, or deflection from the vertical, and direction of the drift. A singleshot directional-survey instrument makes a single photograph of a compass reading of the drift direction and the number of degrees the hole is off vertical. A multi shot survey instrument obtains numerous readings in the hole as the device is pulled out of the well. See directional drilling.

n: A method of measuring the inclination and direction of the wellbore by using a downhole instrument. The well must be surveyed at regular intervals to plot its course accurately.

a measurement of the well path that records the inclination and azimuth of the wellbore using a compass or other device.

n: signals transmitted from an instrument located downhole to a receiving monitor on the surface-a surfacereadout instrument. Downhole telemetry may be transmitted via a special wireline or via mud pulse (much as radio signals are transmitted through the air). Frequently, downhole telemetry is employed in determining the drift angle and direction of a deviated wellbore. See measurement while drilling.

n: The process whereby signals are transmitted from a downhole sensor to a surface readout instrument. This can be done by a conductor line (as on steering tools) or by mud pulses (as in MWD tools (q.v.)).

n: the angle at which a wellbore deviates from the vertical, expressed in degrees, as revealed by a directional survey. Also called angle of deviation, angle of drift, and inclination. See directional survey.

n: refer to hole deviation angle
